Spare Parts for TSTC Hermetic Sliding Door

Views :
Update time : 2025-09-19

The key spare parts for TSTC hermetic sliding door include Main Control Unit, Motor&Gearbox ,Hanging Wheel, Tension Wheel, Key Switch, Hand Induction Switch, Foot Sensor, Backup Battery, Photocell,Handles could be perfectly provided at any time .

TSTC Hermetic Door Parts-TH100-20250603

The Driving Unit adopt the brushless DC Motor and Gearbox with the Rated Power 150W, maximum drive Power 200N, could make the door opening speed and closing speed from 0.3 to 0.55m/s.

The Control Unit with microcomputer control chip is from USA, could adapt automatically to the door weight ,slow position and slow speed.

The Pulley&Hanger also called Carriage Wheel Unit is specially designed to perfectly integrate with the track to prevent derailment.

Foot Sensor / Foot induction switch is the standard part for our hermetic sliding door, contactless design. The Hand Induction Switch and Key Switch could also be provided if needed .

The Backup Battery is the optional part, continue working for at least 30 minutes when power failure, No limitation of operation .

To more details please check the product page with the title TSTC Hermetic Sliding Door .
